Detail produk:
Place of Origin: China
Nama merek: BK
Sertifikasi: ISO9001/ISO14001
Model Number: 50YU2.75
Syarat-syarat pembayaran & pengiriman:
Minimum Order Quantity: 1 set
Harga: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 10-20 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 100 SETS per month
Kontak
Detil Deskripsi produk
Model: 50YU2.75 Tenaga motor: 0.75KW
Bahan Utama: Baja tahan karat dan resin Membosankan: 50mm
Mengalir: 6-12 m Kepala: 10.8-21.6m3 / jam
Aplikasi:: drainase, air limbah, air limbah, air domestik
Cahaya Tinggi:

submersible wastewater pumps

,

commercial sewage pumps





Irrigation Submersible Sewage Pump 50YU2.75, DN50 bore size, wastewater pump






About YU pump


YU series pump is small type pump used for drainage, agricultural irrigation and water treatment. It is a multi-purpose pump with a vortex impeller, featured of small size and light weight. It is durable in use.

.



Working Conditions



  • The medium temperature should not be over 40 , the density 1200Kg/m3 , and the PH value within 5-9



  • During running, the pump must not be lower than the lowest liquid level, See the specific requirements of the drawing of installation dimensions.



  • The maximum diameter of the solid grain going through the pump has not to be larger than 50% of that of the pump outlet.




Specifications



Model No.

50YU2.75

Motor Power

0.75KW

Main Materials

Stainless steel and resin

Bore

50mm

Rated Flow

10.8m3/h

Maximum Flow

21.6m3/h

Rated Head

6m

Maximum Head

12m

Solid passable

Solid diameter ≦ 14

N.W. of pump

8.5kg

Dimension

0.25*0.17*0.33m (length*width*height)

Packing size Approx.

0.27*0.19*0.36m (length*width*height)








Features

  • Vortex type impeller is made from special resin with optimized design.



  • Double silicon carbide mechanical seal separate the motor from the pump seal to provide the motor with a dual protection.



  • Three-phase asynchronous motor,IP54,F,max. working temperature is 155 degrees Celsius. Motor winding with embedded thermal protection device enabling the motor overheating protection.



  • Heavy-duty water-resistant rubber-sheath soft cable is used and special cable sheath and cable seals are also adopted.



  • Brand-name deep groove ball bearing with sufficient load capacity selected.



  • Oil can lubricate and cool the mechanical seal and the air of a certain amount left inside the chamber can lower the pressure accumulatively raised.

  • Shaft made of SUS410 stainless steel, shaft end with sealing device for preventing the shaft being corroded.






Performance curve



Submersible Irrigation Pump 50YU2.75, DN50 bore size , submersible wastewater pumps 0








Structure and materials of pump



Submersible Irrigation Pump 50YU2.75, DN50 bore size , submersible wastewater pumps 1
